Product Overview
Propack Electronics ESD Flooring Systems provide reliable electrostatic dissipation for sensitive electronic manufacturing environments. Our flooring solutions are engineered to maintain surface resistivity within the critical 106–109 Ω range, ensuring personnel and equipment are consistently protected from electrostatic discharge damage.
With over 24 years of industry experience and 600,000+ square feet of ESD flooring installed across India's leading electronics manufacturers, automotive plants, pharmaceutical facilities, and defence establishments, Propack is your trusted partner for complete ESD flooring solutions — from supply and installation to testing and maintenance.
Key Features & Benefits
Superior ESD Protection
Maintains surface resistivity 106–109 Ω per ANSI/ESD S20.20 standards, preventing electrostatic discharge events.
Durable Construction
Heavy-duty formulation withstands industrial foot traffic, pallet jacks, trolleys, and chemical exposure with a 10+ year service life.
Easy Maintenance
Smooth, non-porous surface resists contamination. Simple cleaning protocol maintains conductivity properties throughout service life.
Customizable Finishes
Available in multiple colors and textures. Can be customized with safety markings, aisle designations, and workstation zones.
Temperature Stable
Maintains ESD properties across operating temperatures −10°C to +60°C, suitable for cleanrooms and temperature-controlled environments.
Standards Compliant
Meets ANSI/ESD S20.20, IEC 61340-4-1, and BS EN 61340 requirements. Fully compatible with existing ESD ground monitoring systems.
Technical Specifications
| Surface Resistivity | 106 – 109 Ω (ESD Dissipative) / <106 Ω (ESD Conductive) |
|---|---|
| Test Standard | ANSI/ESD S20.20, IEC 61340-4-1 |
| Thickness | 2–3 mm (standard) / custom thickness available |
| Hardness | Shore D 70–80 |
| Coefficient of Friction | ≥ 0.5 (wet & dry) |
| Chemical Resistance | Resistant to oils, solvents, dilute acids and alkalis |
| Operating Temperature | −10°C to +60°C |
| Color Options | Grey, Blue, Green, Red, Black (custom available) |
| Installation Method | Adhesive bonding to prepared substrate |
| Warranty | 5 years on ESD properties; 2 years on installation |
Applications & Industries
Our Installation Process
Site Survey & Assessment
Our technical team conducts a thorough site survey to assess substrate condition, moisture levels, load requirements, and environmental factors.
Substrate Preparation
Surface grinding, crack filling, and primer application to ensure proper adhesion and a uniform base for flooring installation.
Copper Earthing Grid
Installation of copper earthing strips/tiles at regular intervals, connected to the building's earthing system for effective static dissipation.
Flooring Laying & Bonding
Precision installation using conductive adhesive, ensuring complete coverage, no air pockets, and proper joint sealing.
ESD Testing & Certification
Post-installation testing per IEC 61340 and ANSI/ESD S20.20. Full test report and ESD compliance certificate provided.
