Product Overview
ESD Aprons and Coveralls are mandatory PPE in any ANSI/ESD S20.20 compliant EPA. Regular clothing made from synthetic fibres generates and holds static charges that can discharge destructively to sensitive electronic components. Our ESD garments use carbon-fibre grid or conductive polyester fabric technology to safely dissipate static from the garment surface to the grounded operator.
Propack supplies a complete range: half-aprons for bench operators, full-length lab coats for cleanroom environments, and full-body coveralls for high-risk semiconductor and defence facilities. All garments are certified to IEC 61340-5-1 and ANSI/ESD S20.20, and are available in multiple sizes with custom embroidery/logo options for corporate branding.
Product Range & Features
Three Product Formats
Half apron (waist to knee), full lab coat (collar to ankle), and full-body coverall. All available in standard sizes XS–3XL with custom sizing on request.
Carbon Grid Fabric
Woven carbon-fibre grid in polyester fabric provides surface resistivity of 10⁵–10⁹ Ω. Grid spacing ≤10 mm for reliable charge dissipation across the entire garment surface.
Washable — 50+ Cycles
ESD properties maintained for 50+ industrial washing cycles (40°C, no bleach). Each batch supplied with wash-cycle tracking log for compliance documentation.
Snap-On Ground Points
ESD snaps on cuffs and body panel connect to wrist strap cords or common-point ground, routing charge directly to ground rather than through the operator's skin.
Cleanroom Compatible
Low particle generation versions available for ISO 5–7 cleanrooms. Sealed seams, lint-free construction, and non-shed cuffs meet cleanroom garment standards.
Multiple Colours
Standard colours: white, blue, light grey, green. Custom colours and embroidered logo/name options available for minimum order quantities.
Technical Specifications
| Fabric Type | 65% polyester + 35% carbon fibre grid; or conductive polyester/cotton blend |
|---|---|
| Surface Resistivity | 10⁵ – 10⁹ Ω (per IEC 61340-4-9) |
| Charge Decay | < 2 seconds from 1 kV to <100 V |
| Wash Durability | 50+ cycles at 40°C (properties verified post-wash) |
| Available Styles | Half apron, Lab coat (3/4 and full sleeve), Coverall (1-piece and 2-piece) |
| Sizes | XS, S, M, L, XL, 2XL, 3XL (custom on request) |
| Grounding Points | ESD snap buttons at wrist cuffs (2 per garment) |
| Standard Colours | White, Blue, Light Grey, Green |
| Compliance | ANSI/ESD S20.20, IEC 61340-5-1, EN 1149-5 |
| Packaging | Individual poly bag; custom carton quantities available |
