Product Overview
Propack ESD Epoxy Coatings are high-performance, solvent-free floor coating systems specifically formulated for electrostatic sensitive manufacturing environments. The seamless, joint-free surface eliminates contamination traps, making these coatings ideal for cleanrooms, pharmaceutical production areas, and precision electronics assembly.
Our epoxy ESD coatings are available in conductive (104–106 Ω) and dissipative (106–109 Ω) formulations. The two-component system provides outstanding adhesion to concrete substrates, excellent chemical resistance, and a durable surface that retains its ESD properties for 15+ years under normal industrial use.
Key Features & Benefits
Seamless Surface
No joints, cracks, or grout lines. Zero particle traps — perfect for cleanroom ISO Class 6–8 environments requiring controlled contamination.
Chemical Resistance
Excellent resistance to PCB chemicals, flux, isopropyl alcohol, dilute acids, alkalis, and cleaning agents common in electronics manufacturing.
Colour-Through Design
ESD pigmentation goes through the full depth — colour and conductivity properties maintained even as the surface wears over time.
Dual Formulation
Choose conductive (<106 Ω) for high-risk areas or dissipative (106–109 Ω) for general EPA zones. Both ANSI/ESD S20.20 compliant.
Low Dust Generation
Epoxy surface does not generate particles under foot traffic. Critically important for PCBA, semiconductor, and medical device manufacturing.
Self-Levelling Option
Self-levelling formulation available for uneven substrates, producing a perfectly flat surface with minimal surface preparation requirements.
Technical Specifications
| Surface Resistivity (Dissipative) | 106 – 109 Ω per ANSI/ESD S20.20 |
|---|---|
| Surface Resistivity (Conductive) | 104 – 106 Ω per IEC 61340 |
| System Type | Two-component solvent-free epoxy |
| Coat Thickness | 1.5 mm (screed coat) + 0.3 mm (seal coat) = 1.8 mm total |
| Compressive Strength | ≥ 60 N/mm² |
| Bond Strength | ≥ 2.0 N/mm² (concrete substrate) |
| Chemical Resistance | IPA, acetone, MEK, dilute acids/alkalis, oils |
| Pot Life at 25°C | 45 minutes (mixed) |
| Full Cure Time | 7 days at 20°C |
| Available Colours | Light Grey, Mid Grey, Dark Grey, Green, Blue, RAL custom |
